12MP PTZ Video Conference Camera Wall Mount High Definition DVI SDI Interface

Name: 12MP PTZ Video Conference Camera Wall Mount High Definition DVI SDI Interface
Brand: WINSAFE
Price: 1 USD

Brand Name : WINSAFE

Model Number : UHV-12X-S

Certification : CE,FCC

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T, Western Union

Supply Ability : 2000pcs/month

Delivery Time : 5-8 work days

Packaging Details : Neutral Packing

Sensor : 12MP HD CMOS Sensor

Video System : 1080P

Zoom : 12X

Control Port : RS232 / RS485

Focus : Auto / Manual

White Balance : Auto / Manual

Input Voltage : DC12V

Contact Now

12MP PTZ Video Conference Camera Wall Mount High Definition DVI SDI Interface

Advantages

※ Super high video quality: with Ambarella A9 DSP 1/2.3" 12MP Sensor and high quality 12x lens
※ Fast switching between different video formats: only 3 senconds needed
※ Fast and accurate focus performance
※ Easy firmware upgrade: no need to open the camera housing
※ Daisy Chain function: with both Visca in and Visca out port
※ With powerful functional remote controller
※ Multi language OSD menu: support English, Chines, Russia, Spanish
※ 2 years warranty time

Features

※ 3G-SDI & DVI-I simultaneously output
※ Zoom: 12X optical Zoom +2X Digital Zoom
※ 1920x1080p 59.94fps high resolution
※ 72.5° ultra wide FOV
※ Ultra smooth PTZ mechanism
※ Accurate PT motro control
※ Up to 128 presets
※ Effective RS232/RS485 seria control
※ Effective 3D-noise reduction function
※ Image flip function support upside-down installation
※ Mounts: Wall mount & in-ceilling mount available
※ Sony Visca and Pelco D/P protocol controls

Technical Specification

Model No.	UHV-12X-S
Sensor	1/2.3 inch high quality, 12MP HD CMOS Sensor
Video System	DVI Port	3G-SDI Port	CVBS port(optional)
	1080p59.94/50/29.97/25; 720p59.94/50/29.97/25	1080p59.94/50/29.97/25; 720p59.94/50/29.97/25	Analog Video
Zoom	12x optical zoom + 2x digital zoom
View Angle	6.3°(wide) - 72.5°(tele)
Pan Rotation Angle	- 170° - +170°
Tilt Roation Angle	- 30° - + 90°
Pan Rotation Speed	0° - 120° /s
Tilt Rotation Speed	0° - 80° /s
Preset	128
Control Port	RS232/RS485
Video Port	DVI-I, 3G-SDI, CVBS
SNR	More than 50dB
Focal Length	f=3.92(wide) - 47.32mm(tele)
Minimum Lux	0.01Lux
White Balance	Auto/Manual
Focus	Auto/Manual
Iris	Auto/Manual
Electronic Shutter	Auto/Manual
BLC	Auto/Manual
Input Voltage	DC12V
Dimension(W x H x W)	220mm x 173mm x 117mm
Net Weight	1.25KG

Application

HD PTZ Video Coneference Camera are good used on video conference system, Telemedicine, Education Recordered, Church etc.

Our services

OEM service : we can offer OEM and ODM services for our clients
Delivery lead time : sample order in 3-5 working days, bulk order in 7-15 working days

Quality warranty

2 years for free repair
Lifetime service for continued cooperating customers
Price term: EXW factory
Delivery terms: by express (DHL/FedEx/TNT/UPS/EMS/China post), by air or by sea

FAQ

MOQ : 1pc for sample, at least 10pcs after sample order
Delivery lead time :sample order in 3-5 working days, bulk order in 7-15 working days

Why choose us

Winsafe Technology Co Ltd is a HD PTZ video conference camera manufacturer
We will try our best to find the products you need, we will provide you with the most satisfactory service
Contact us to learn more
Welcomes you to visit our factory
